W25Q16DW
8.
ELECTRICAL CHARACTERISTICS
8.1 Absolute Maximum Ratings (1)
PARAMETERS
Supply Voltage
Voltage Applied to Any Pin
Transient Voltage on any Pin
Storage Temperature
SYMBOL
VCC
V IO
V IOT
T STG
CONDITIONS
Relative to Ground
<20nS Transient
Relative to Ground
RANGE
–0.6 to VCC+0.6
–0.6 to VCC+0.6
–1.0V to
VCC+1.0V
–65 to +150
UNIT
V
V
V
° C
Lead Temperature
T LEAD
See Note
(2)
° C
V ESD
Electrostatic Discharge Voltage
(3)
Human Body Model (HBM)
Machine Model (MM)
–2000 to +2000
–200 to +200
V
Charge Device model (CDM)
–750 to +750
Notes:
1. This device has been designed and tested for the specified operation ranges. Proper operation outside
of these levels is not guaranteed. Exposure to absolute maximum ratings may affect device reliability.
Exposure beyond absolute maximum ratings may cause permanent damage.
2. Compliant with JEDEC Standard J-STD-20C for small body Sn-Pb or Pb-free (Green) assembly and the
European directive on restrictions on hazardous substances (RoHS) 2002/95/EU.
3. ESD Test Condition:
HBM – JESD22-A114C.01
MM – EIA/JESD22-A115-A
CDM – JESD22-C101-C
8.2 Operating Ranges
PARAMETER
SYMBOL
CONDITIONS
SPEC
MIN MAX
UNIT
Supply Voltage (1)
Ambient Temperature,
Operating
VCC
T A
F R = 80MHz,
F R = 104MHz,
Industrial
f R = 50MHz
f R = 50MHz
1.65
1.7
–40
1.95
+85
V
°C
Note:
1. VCC voltage during Read can operate across the min and max range but should not exceed ±10% of
the programming (erase/write) voltage.
Publication Release Date: September 06, 2012
- 69 -
Revision F
